32
SINGLE PUMP UNITS — ENGLISH
SINGLE PUMP UNITS — SI
30XA
UNIT SIZE
MOUNTING WEIGHT (lb) MCHX CONDENSER COILS
A B C D E F Total
090 1201 2754 1087 900 1944 1199 9085
100 1226 2814 1123 924 1995 1224 9306
110 1239 2855 1145 945 2027 1229 9441
120 1272 2893 1147 947 2059 1263 9580
30XA
UNIT SIZE
MOUNTING WEIGHT (lb) MCHX CONDENSER COILS
A B C D E F G H Total
140 1897 1444 1609 1606 1078 810 1584 1699 11,726
160 1949 1469 1626 1635 1103 824 1603 1750 11,958
30XA
UNIT SIZE
MOUNTING WEIGHT (kg) MCHX CONDENSER COILS
A B C D E F Total
090 545 1249 493 408 882 544 4121
100 556 1276 510 419 905 555 4221
110 562 1295 519 429 920 558 4282
120 577 1312 520 430 934 573 4346
30XA
UNIT SIZE
MOUNTING WEIGHT (kg) MCHX CONDENSER COILS
A B C D E F G H Total
140 860 655 730 728 489 367 719 771 5319
160 884 666 737 742 500 374 727 794 5424
30XA090-120 30XA140,160
LEGEND
MCHX — Microchannel Heat Exchanger
Fig. 15A — Unit Mounting Weights (Units with MCHX Condenser Coils) (cont)
a30-4420 a30-4421
A B C
F E D
COOLER SIDE
COMPRESSOR SIDE
A B C D
H G F E
COOLER SIDE
COMPRESSOR SIDE
