E. “Info Timing“ function window
PG-MT1 will display the current output’s timing format on
the LCM.
Path: Main -> Info-> Timing
Operation in “Info Timing” window
“▲”, “▼” button: Change the value
“Menu/Back” button: Back to the “info” function window.
E-1. “Setup #1“ function window
Path: Main -> Setup
Operation in ““Setup #１” window
“ ▲ ”, “►”: Change the different setting:
R: Enable Red color output.
G: Enable Green color output.
B: Enable Blue color output.
Rev: Enable Pattern reverse
AUD: Enable audio out (HDMI + analog + coxial).
“O”: enable, “X”:disable
“▼”: Change to “Setup #2” page.
“Menu/Back” button: Back to the “Main” function window,
and stop
“
“ : Change the value.
E-2. “Setup #2“ function window
Path: Main -> Setup
-6-
Operation in “Setup #2” window
“ ▲ ”, “►”: Change the different setting:
Ｍ OD: Switching to HDMI mode.
- DVI: output DVI mode
- H8: output HDMI 8-bit mode
- H10: output HDMI 10-bit mode
- H12: output HDMI 12-bit mode
CSC: Switching to Video Type RGB/Y444/Y422
HDCP: Enable/Disable HDCP
‘O”: enable, “X”:disable.
“▲”: Change to “Setup #1” page.
“▼”: Change to “Setup #2” page.
“Menu/Back” button:Back to the “Main” function window,
and stop
“
“ : Change the value.
E-3. “Setup #3“ function window
Operation in “Setup #３ window
“ ▲ ”, “►”: Change the different setting:
Ｍ ove: Video output keep scrolling
- ▲ : video scroll to left direction
- ►: video scroll to right direction
- X: video stop to scroll
Block: Video output a moving block pattern
- ▲ : block pattern moving to left
- ►: block pattern moving to right
- X: disable moving block
“▲”: Change to “Setup #2” page.
“Menu/Back” button: Back to the
“Main” function window, and stop
“
“ : Change the value.
-7-
**PG-MT1 Output signal specification chart:
Sync Polarity
NO Resolution
Refresh
Rate
(Hz)
Pixel Freq
(MHz)
Hor Ver
1 640x350 85 31.5 P N
2 640x400 85 31.5 N P
3 640x480 60 25.175 N N
4 640x480 72 31.5 N N
5 640x480 75 31.5 N N
6 640x480 85 36 N N
7 720x400 85 35.5 N P
8 800x600 56 36 P P
9 800x600 60 40 P P
10 800x600 72 50 P P
11 800x600 75 49.5 P P
12 800x600 85 56.25 P P
13 848x480 60 33.75 P P
14 1024x768 60 65 N N
15 1024x768 70 75 N N
16 1024x768 75 78.75 P P
17 1024x768 85 94.5 P P
18 1152x864 75 108 P P
19 1280x720 60 RB 64 P N
20 1280x720 60 74.25 P P
21 1280x720 75 95.75 N P
22 1280x768 60 RB 68.25 P N
23 1280x768 60 79.5 N P
24 1280x768 75 102.25 N P
25 1280x768 85 117.5 N P
26 1280x800 60 83.5 N P
27 1280x960 60 108 P P
28 1280x960 85 148.5 P P
29 1280x1024 60 108 P P
30 1280x1024 75 135 P P
31 1280x1024 85 157.5 P P
32 1360x768 60 85.5 P P
33 1366x768 60 85.5 P P
34 1400x1050 60 RB 101 P N
35 1400x1050 60 121.75 N P
36 1400x1050 75 156 N P
37 1440x900 60 106.5 N P
38 1440x1050 60 125.25 N N
-8-
◄► Ｘ Ｘ
▼ ［Ｍｏｖｅ］Ｂｌｏｃｋ
◄► Ｈ ８ ＲＧＢ Ｏ
▼ ［ＭＯＤ］ＣＳＣ ＨＤＣＰ
◄► Ｏ Ｏ Ｏ Ｘ Ｏ
▼ ［Ｒ］Ｇ Ｂ ＲＥＶ ＡＵＤ
▲ Ｐｉｘ Ｃｌｋ：１４８．５００ＭＨＺ
▼ ＶＩＤＥＯ ＣＯＤＥ： １６
［Ｔｉｍｉｎｇ］
