SK-ACP Installation & Operating Manual
C-2
NOTE: The default baud rate is 9600 baud. A 38,400 baud rate is recommended. You can change the baud
rate of a 28SA-Plus using the PD-26 program deck, and the SK-ACP using SK-NET
TM or a terminal program.
REMOTE SITE MODEM CONFIGURATION with 28SA-PLUS
RS-485 NETWORK MODULE
SK-NM485
TELCO
LINE
SK-MDM 28SA-Plus
MODEM
Up to 128
28SA Plus Units
RS-232 GATEWAY
¿
¿
¿
REMOTE SITE MODEM CONFIGURATION WITH SK-ACP
TELCO
LINE
SK-MDM
MODEM
SK-ACP
SK-ACP
SK-ACP
Up to 100 SK-ACP’s
RS-232
GATEWAY
¿
RS-485
NETWORK
¿
¿
¿
¿
