AERCO KC1000 Boiler July 2011 User Manual

Kc series gas fired boiler system

REVISED JULY 7, 2011

GF-109

OMM-0016_0B

KC Series Gas-Fired Boiler

USER MANUAL

Applicable to Serial Number G-11-0695 and above

KC Series

Gas Fired

Boiler System

Semi-Instantaneous, Condensing,

Forced Draft,

Natural Gas and Propane Fired,

Hot Water Boiler

1,000,000 BTU/HR Input

Patent No. 4,852,524
