The adaptive front lighting system
(AFS) helps to improve visibility
during nighttime driving. The AFS
controls the aiming direction and
lighting distribution of the low
beams according to the amount of
turn applied to the steering wheel
during cornering or turning. To turn
the AFS on, turn the ignition to ON
(II), and turn the headlights on.
If the AFS indicator comes on and
starts blinking while driving, pull to
the side of the road when it is safe,
and turn off the engine. If the AFS
indicator keeps blinking, or starts
blinking again while driving after
turning the ignition switch to ON (II),
the AFS is not working properly (see
page
). Have the AFS inspected
by your dealer.
When the AFS indicator comes on,
you will also see a ‘‘CHECK
ADAPTIVE FRONT LIGHTING
SYSTEM’’ message on the multi-
information display (see page
).
Without AFS, your vehicle still has
normal lighting ability to continue
driving.
Adaptive Front Lighting System (AFS)
AFS Indicator
Inst
ru
m
e
nt
s
a
nd
Cont
ro
ls
107
