Airbag System Components
Additional Information About Your Airbags
24
(3)
(14)
(9)
(9)
(10)
(1)
(6)
(7)
(11)
(4) (5)
(17)
(16)
(8)
(15)
(16)
(2)
(13)
(12)
(5)
(11)
(4)
(6)
(7) Driver’s Seat Position Sensor
(8) Front Passenger’s Weight Sensors
(9) Front Impact Sensors
(10) Passenger Airbag Off Indicator
(11) Side Impact Sensors (First)
(12) Occupant Position Detection System (OPDS) Sensors
(13) Front Passenger’s Weight Sensors/OPDS Sensors Control Unit
(14) Supplemental Restraint System (SRS) Indicator
(1) Driver’s Front Airbag
(2) Passenger’s Front Airbag
(3) Control Unit
(4) Front Seat Belt Tensioners
(5) Side Airbags
(6) Side Curtain Airbags
(15) Rollover Sensor
(16) Side Impact Sensors (Second)
(17) Seat Belt Buckle Tensioners
