© Inovonics, 2011 - www.inovonics.com 9
15.2 Bosch D9412GV2 / D7412GV2 Control Panel Zone
Examples of programming for alarm points:
Note: For UL installations, the control panel must be programmed to indicate an alarm if the system is in an armed condition and an RF jamming signal
occurs at the receiver.
Point Point Point Point
EN4232MR Output Function Assignment Text Type Response Options
Alarm 1 1
Alarm 2 2
Repeater AC Loss 3 RF REPEATER AC 0 3 Buzz on fault = 2
RF Point Low Battery 4 RF PT LOW BATT 0 3 Buzz on fault = 2
RF Point/Receiver Tamper 5 RF PT TROUBLE 2 3 Buzz on fault = 1
RF Point Inactive 6 RF PT INACTIVE 0 3 Buzz on fault = 2
Receiver Power Loss 7 RF RECVR POWER 2 3 Buzz on fault = 2
RF Jam 8 RF SYSTEM JAMMED 0 3 Buzz on fault = 1
Point Point Point Point
EN4232MR Output Function Assignment Text Type Response Options
Intrusion Front Door 1 1
Holdup Holdup 0 0 Silent bell = Yes
