16 DMP XR500 Control Panel Wiring and Programming Information
16.1 Typical EN4232MR Receiver Connection to DMP XR500 Control Panel
EN4232MR Function
EN4232MR
Terminal
Panel Terminal
Keypad Text
Power in (12V DC)
Vs
(7) RED
n/a
Ground
GND
(10) BLK
n/a
NC (1)
Alarm 1
C (1)
(14) GND
Zone 1
(Follower)
NO (1)
(13) Z1
(user text)
NC (2)
Alarm 2
C (2)
(14) GND
Zone 2
(Follower)
NO (2)
(15) Z 2
(user text)
NC (3)
Repeater AC Loss
C (3)
(17) GND
Zone 3
(Follower)
NO (3)
(16) Z 3
RF Repeater AC
NC (4)
RF Pt Low Battery
C (4)
(17) GND
Zone 4
(Latching)
NO (4)
(18) Z 4
RF Pt Low Batt
NC (5)
RF Pt Tamper
C (5)
(20) GND
Zone 5
(Latching)
NO (5)
(19) Z 5
RF Pt Trouble
NC (6)
RF Pt Inactive
C (6)
(20) GND
Zone 6
(Follower)
NO (6)
(21) Z 6
RF Pt Inactive
Power Loss
POWER LOSS
(22) Z 7
Zone 7
(Follower)
GND
(23) GND
RF Recvr Power
Receiver Tamper
NO (TAMP) *
n/a
(Follower)
C (TAMP) *
n/a
RF Jam
NC (JAM)
(24) Z 8
Zone 8
(Follower)
C (JAM)
(23) n/a
RF System Jammed
* Receiver Tamper and Transmitter Tamper can be combined on one loop.
Connect a 2K-ohm resistor from TAMP NO (normall open) to TAMP C (common).
Wire from TAMP NO to 5 NO.
Wire from TAMP C to 5 C.
