15 Bosch D9412GV2 / D7412GV2 Control Panel Wiring and Programming Information
15.1 Typical EN4232MR Receiver Connection to Bosch D9412GV2 / D7412GV2 Control Panel
EN4232MR Function
EN4232MR
Terminal
Panel Terminal
Keypad Text
Power in (12V DC)
Vs
(3) + Aux Power
n/a
Ground
GND
(9) Common
n/a
NC (1)
Alarm 1
C (1)
(12) Common
PT 1
(Follower)
NO (1)
(11) Point 1
(user text)
NC (2)
Alarm 2
C (2)
(12) Common
PT 2
(Follower)
NO (2)
(13) Point 2
(user text)
NC (3)
Repeater AC Loss
C (3)
(15) Common
PT 3
(Follower)
NO (3)
(14) Point 3
RF Repeater AC
NC (4)
RF Pt Low Battery
C (4)
(15) Common
PT 4
(Latching)
NO (4)
(16) Point 4
RF Pt Low Batt
NC (5)
RF Pt Tamper
C (5)
(18) Common
PT 5
(Latching)
NO (5)
(17) Point 5
RF Pt Trouble
NC (6)
RF Pt Inactive
C (6)
(18) Common
PT 6
(Follower)
NO (6)
(19) Point 6
RF Pt Inactive
Power Loss
POWER LOSS
(20) Point 7
PT 7
(Follower)
(21) n/a
RF Recvr Power
Receiver Tamper
C (TAMP) *
n/a
(Follower)
NO (TAMP) *
n/a
RF Jam
NC (JAM)
(22) Point 8
PT 8
(Follower)
C (JAM)
(21) Common
RF System Jammed
* Receiver Tamper and Transmitter Tamper can be combined on one loop.
Connect a 2K-ohm resistor from TAMP NO (normall open) to TAMP C (common).
Wire from TAMP NO to 5 NO.
Wire from TAMP C to 5 C.
