HI HLPT SERIES LOAD POINT ASSEMBLY
Page 8
Step 3. Check all cables for cracks, cuts or crimp-
ing. Check for any abrasions on the cables.
Step 4. Look for structural changes in the scale or
supporting structures.
Step 5. Look for binding of any kind on the load
point assembly.
Step 6. Refer to your Hardy Manual for informa-
tion on how to troubleshoot using Inte-
grated Technician. For your convenience
this manual is available on the Hardy Web
site at: http://www.hardyinst.com on the
support page. If you do not have access to
the internet, contact your local Hardy Rep-
resentative for information as to where to
get this and other manuals for Hardy prod-
ucts.
Step 7. Get the Load Sensor certification sheets
for referencing while troubleshooting. The
certifications are available to you 24 hours
a day at our Web Site: http://www.hardy-
inst.com
If you find any of the problems stated above, replace
the part that is damaged.
Electrical Tests for
Load Point
Assembly
Problems
Zero Balance
Test
Problem: Changes in the Zero Balance.
Cause: Load Cell has been overloaded.
Remedy:
Step 1. Use a millivolt meter or the Integrated
Technician feature of the HI 2151/30WC
(See Physical Checks, Step 6) and measure
the LPS output under “no load” condi-
tions. The reading should be less than 1%
of the full scale output.
NOTE: Sensors can shift up to about 10% of their full scale
and still function correctly.
