Calibration:
Section used to calibrate the instrument to the sensor(s) used.
C2 – Electronic Calibration
1) Remove all weight from the scale.
2) Press Do C2 Cal.
3) Place a verification weight on the scale to ensure calibration is
successful.
Hard Cal‐
1) Input the Span Weight. The span weight should be about 80% of
the scale capacity.
2) Input Cal Low Weight. With nothing on the scale, the Cal Low
Weight is 0, with 5 lbs on the scale, the Cal Low Weight would be 5.
3) Press Do Cal Low to set the low point on the calibration curve.
4) Place the Span Weight onto the scale.
5) Press Do Cal Hi.
Refer to User’s Guide if adjustments to other calibration‐related
parameters are required.
Communication:
Section used for setting up communications to the instrument.
Ethernet TCP/IP
1) Connect an Ethernet cable between the instrument’s RJ45
connector and a PC, then power up the instrument. A cross‐over
cable is not required, but can be used.
2) The instrument will auto‐negotiate settings suitable for a variety of
operating systems and network configurations. Wait approximately
15 seconds and check to see if the green light of the Ethernet port is
on and blinking – if so, skip to step 8 – you are connected.
3) If the green light on the Ethernet port does not light up, check that
the unit’s Enable DHCP is turned off and follow steps 4 through 9.
4) Using the unit’s Fixed IP address (the default is 192.168.000.100),
the PC must now be assigned a unique IP address (for example,
192.168.000.101)
