7| Accessories
A special intermediate flange, located below the discharge line valve, is used to attach the sensor
element (Part no. 04175). Wire the thermal protection thermostat in series with the control line.
Technical Data:
Switching voltage max. :
24 V DC
Switching current max. :
2.5 A at 24 V DC
Switch-off temperature :
145 °C ± 5 K
Switch-on temperature :
approx. 115 °C
7.1 Thermal protection thermostat (Item No. 07595)
