faytech Industrial Motherboard Series - Manual (Page 7)

Storage
USB
Display I/O
Audio I/O
LAN I/O
Serial port
PS/2 port
DIO
Fan
RTC
I/O
2 x SATA 3Gb/s ports
6 x USB 2.0 ports (2 ports at mid-board, 4 ports on rear I/O)
1 x LVDS connector, 1 x VGA connector, 1 x HDMI port
Mic-In, Line-Out, S/PDIF onboard headers
Amplifier onboard header
HDMI support audio
2 x RJ-45 ports on rear I/O
1 x 5V/12V RS232/RS485 port on rear I/O (COM1)
1 x PS/2 keyboard / mouse connector
8-bit Digital I/O interface (4-in/4-out)
1 x Chassis fan connector (4-pin)
Internal RTC
3 x RS232 onboard headers (COM2, COM3, COM4)
Back panel I/O ports 1 x HDMI port
I/O Placement
1 x COM port (RS232/485)
2 x LAN (RJ-45) port
4 x USB 2.0 ports
Internal I/O
connectors
1 x Lockable DC power port (12V)
1 x VGA pin header
1 x 12V DC power connector (2-pin)
2 x SATA 3Gb/s connectors
1 x 4-pin SATA power connector
1 x PS/2 keyboard/mouse connector (6-pin)
3 x RS232 COM connectors
1 x LVDS connector
1 x USB 2.0 header supports additional 2 USB 2.0 ports
1 x 5-pin LCD power connector
1 x Full Height Mini Card slot
1 x SIM card connector
1 x Half Height Mini Card slot
1 x 4-pin audio amplifier connector
1 x S/PDIF output pin header
1 x DIO connector
1 x PCIeX1 Straddle
1 x Line-Out / Mic-In audio pin header (AAFP)
