2.4 Central Processing Unit (CPU)
The motherboard comes with an integrated Intel ® Atom™ processor N2600 /
N2800 (optional).
Integrated Intel ®
Atom™ processor
faytech Industrial Motherboard Series Integrated Intel ® Atom™ processor
2.5 System memory
This motherboard comes with one Double Data Rate 3 (DDR3) Small Outline Dual
Inline Memory Modules (SO-DIMM) socket. The figure illustrates the location of the
DDR3 DIMM socket:
DIMM_A1
faytech Industrial Motherboard Series DDR3 DIMM socket
faytech Industrial Motherboard Series
PCIxe1 Straddle
3
2-6 faytech Motherboard
