6.

LCD inverter power setting jumper (3-pin LCD_POWER_SEL1)

LCD_POWER_SEL1

2

1

2

+12V

(Default)

+5V

faytech Industrial Motherboard Series LCD inverter power setting jumper

Pins

1-2

2-3

+12V (Default)

+5V
