faytech Industrial Motherboard Series - Manual (Page 6)

1.3
CPU
Memory
Chipset
I/O Chipset
LAN
Audio
Specifications
SYSTEM
Integrated Intel Atom™ processor N2600 / N2800 (optional) ®
1 x SO-DIMM, max. 2GB, DDR3 800 / 1066MHz, non-ECC, un-buffered
Memory (max. 4GB for N2800)
Single channel memory architecture
Intel ® NM10
Fintek 81866D-I
2 x Realtek ® 8111F PCIe Gigabit LAN controllers
1 x Audio Amplifier EUA 2012A
1 x Realtek ® ALC887 8-channel high definition audio CODEC
2 x Mini Card slots with PCIe and USB interface (1 x Full Height with SIM
card interface, 1 x Half Height), 1 x PCIe 1 x slot Expansion slot
BIOS
H/W Status Monitor
Watchdog Timer
Smart Fan Control
Wake On LAN / PXE
Power States
Graphics Chipset
Graphics Multi Display
Resolution
LVDS Inverter Control
Battery
Power requirement
Power compliance
Operating
temperature
Operating humidity
Form factor
EMI
64Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.0, Wfm 2.0, SM BIOS, ACPI
3.06
Monitors CPU/system temperature
Monitors chassis fan speed
Yes
Yes ( WOL, PXE)
S3, S4, S5
®
Monitors Vcore, 3.3V/5V/12V voltages
1~255 steps by software program
AMD HD7410M with 512M memory (optional)
LVDS+HDMI, VGA+LVDS, VGA+HDMI
VGA: Up to 1920 x 1200 @60Hz (optional)
HDMI: Up to 1920 x 1200 @60Hz
LVDS: Up to 2048 x 1536 @60Hz, 24 bit dual channel
Graphics
Environment, Power, and ME
Lithium battery
1 x DC connector on rear I/O
Compliant with Eup/ErP
14
o
F~131
o
F (-10
o
C~55
o
C)
0%~90% relative humidity, non-condensing
EPIC form factor: 4.53 in. x 6.5 in. (11.5 cm x 16.5 cm)
CE, FCC
1 x onboard 2-pin power connector
(continued on the next page)
1-2 faytech Motherboard
Voltage / PWM, 1 x DC 5V/12V for LCD backlight inverter board
