3. Switching between the functions
Because the A-191 has two separate functions in it,
which share some of the controls and outputs, at any
one time it can be used either as a MIDI-CV interface
or as a Shepard Generator. To switch between the two
you simply press a button (see below).
H The A-191’s controls and in / outputs for
each function are explained in their
respective sections of this manual.
7 Mode button
To switch between functions, press the lowest mode
button 7
7 7 7 .
8 LED
LED 8 lights when the Shepard Generator is active;
otherwise it’s the MIDI-CV interface which is active.
H If the A-191 receives MIDI clock, LED 8
flashes (see chapter. 4.2, " MIDI In).
4. MIDI-CV interface
4.1 Basics
In its MIDI-CV mode, the A-191 provides a MIDI-CV
converter, and a MIDI-synchronized LFO.
Whenever the A-191 receives relevant MIDI control-
ler messages on the channel you’ve selected, it con-
verts them into control voltages (in a 0 V to +5 V
range), and sends these out on the corresponding CV
outputs. Table 1 on page 4 lists the MIDI controllers,
their corresponding CV output sockets, and their de-
fault values.
H After switching your A-100 system on, pres-
sing the Store/Reset button 9 sets the
voltages at the CV outputs to the default
values (see table 1).
If you’re running your A-100 from a MIDI
sequencer, you’ll need to save the appro-
priate MIDI controller messages at the begin-
ning of a Song, to initialise the A-191’s CV
outputs correctly.
