Trimming Potentiometers Overview
Name Function Explanation Factory default
P17 VCO Scale adjusts the 1V/octave characteristics of the
socket "VCO F" or the bus CV adjusted to 1.00V/octave
P18 VCO Offset adjusts the VCO frequency offset 64 Hz @ center position of the VCO Tune
control and Range switch in center
position
P19 VCO Octave Switch + adjusts the upper position of the VCO range
switch (+ 1 octave) adjusted to +1 octave
P20 VCO Octave Switch - adjusts the lower position of the VCO range
switch (- 1 octave) adjusted to -1 octave
P21 VCF Scale adjusts the 1V/octave characteristics of the
socket "VCF F" or bus CV (if the tracking
switch is in the lower position "full") adjusted to 1V/octave, VCF in self-
oscillation (Resonance control fully CW)
P22 VCF Offset adjusts the VCF frequency offset ~ 10 Hz @ CCW position of the VCF Frq.
control, VCF in self-oscillation
(Resonance control fully CW, all VCF
modulations off)
R23 Minimum VCA level adjusts the minimum VCA level (i.e. when
VCA A control is fully CCW and all VCA
modulations are off) 10k (a smaller value leads to a smaller
minimum VCA level)
Remark: The specifications in this appendix are only for experienced users. Please do not change the settings of the
jumpers or potentiometers if you do not have sufficient experience. Modules that have been misadjusted by the customer
(jumpers and/or trimming potentiometers) are treated as repairs at the owner's expense ! The warranty is void if the module
is modified or misadjusted by the customer (exception: changing the jumper settings is allowed without loosing the
warranty).
