Network Video Server/IP Camera User Manual
29
『 Channel』2/4 channel DVS, select different channel to configure
『 Channel Name』set the channel name of camera
『 Encode Mode』support 3 streams: main stream, sub-stream, mobile steam
『 Encoding Format』set encoding format, support H.264
『 Frame Rate』set the frame rate of encoding, which means how many frames of image DVS/IP
Camera can compose in 1 second.
『
Video Size』set the size for the image of video encoded by DVS/IP Camera, carry out
corresponding setting depending on which encode mode is selected.
『
Stream Mode』Constant Bit Rate and Constant Quality options, when Constant Bit Rate is
selected, the camera will control the bit rate within the range of set value of constant bit rate; when
Constant Quality is selected, encoding will be carried out according to the option of『Encoding
Quality』
『
Encoding Quality』five encoding qualities are available for option: Best, Good, General, Not
Good, Poor
『
Constant Bit Rate』DVS/IP Camera will carry out encoding according to the value of Constant
Bit Rate
『
I frame interval』means the number of P frames or B frames between key frames (I frames) in
the frames (I frames, B frames, P frames) encoded by DVS/IP Camera, that is, how many frames
have been encoded when a key frame appears
『
Bit rate』means the quantity of stream in bps encoded by encoder in 1 second. It can be adjusted
continuously from 16k to 16000k.
4.2. Color Setting
General
The color setting interface is shown below; in this setting item, you can configure video brightness,
contrast, saturation, sharpness, hue and automatic diaphragm etc options of DVS/IP Camera
