Digital Video Recorder User Manual
Fig 2.3 Front Panel
1 Heat emitting window Heat emission
2 HDD lock Lock up the hard-disk drive
3 Digital button Input digitals or choose camera
4 Multi-screen button Change screen display like single, 4, and 8 screens
5 Direction Direction buttons. Move cursor in setup or pan/title PTZ
6 Enter button To confirm the choice or setup
7 Indicators Working indicators of power and network, etc.
8 Shuttle Control the playback speed
6
