Digital Video Recorder User Manual
111
Appendix D
DVR Specifications for 8-channel DVR
Compression format
Standard H.264 Baseline
Video output
Composite˖1.0V p-p/75
ȍˈBNC×2 S-VIDEOX1, VGAX1
Video input
Composite˖1.0V p-p/75
ȍˈBNC×8
Display Resolution
720*576 (PAL), 720*480 (N
TSC)
Record Resolution
352*288 , 704*576 (PAL
80 (NTSC)
), 352*240 , 704*4
Display Frame Ra
200FPS (PAL), 240FPS (NTS
te C)
Record Frame Ra
200FPS, 50FPS (PAL) ; 240FPS, 60FPS (NTSC)
te
Audio input
-8dB~ 22k, RCA X8
Audio output
-8Db~92dB, RCA X1
Alarm input
NO or NC 8CH
Alarm output
4CH
Record Mode
Manual / Sensor /Timer / Motion detection
Simplex/Duplex/Triplex Pentaplex
Network Interface
RJ45 (LAN, INTERNET)
PTZ control
YES
Communication int
RS485, USB2.0 x 2(one fo
r for USB mouse), PS/2 x 1,
erface
r backup, anothe
Hard disk info
SATA x 3+DVD-RW x 1
Remote controller
YES
Power supply
220V or 110V
