24
3.5.3. RS232 serial port parameter setting
Server supports RS232 serial port transparent transmission function, data can be transmitted from
client to server via network, server send the data to the serial port.
3.5.4. PTZ management FAQ
1 ᇬCan not control dome, the possible reasons include: hardware errors for example PTZ power supply
is not connected, RS485 cable connection is not correct. Check if PTZ protocol is properly set.
PTZ protocol, address, and baud rate must correspond with the dome which is using. Then check if
the control speed value is set as 0. if these operations can not solve problems, please contact our
technical support department.
2 ᇬPlease contact our engineer to upgrade the protocol, if your protocol is a private protocol.
3.6. Alarm and event management
This section describes the video server alarm parameter setting and the responding when video
servers received an alarm
Alarm type
Combined
action
Trigger event Alarm Attribute
Video motion
alarm can combine
camera output
1. Images capture
and upload to client,
2. auto call the speed
dome to the
appointed presetting
client configurable
and save in log automatic after
setting
Sensor input
alarm can combine
camera output
1. Images capture
and upload to client,
2. auto call the
speed dome to the
appointed presetting
client configurable
and save in log automatic after
setting
Video loss
alarm can combine
camera output 1. Images capture
and upload to client
client configurable
and save in log automatic after
setting
Sensor output -------- trigger alarm device ---------
automatic or
manual after
setting
Table 7
