Checkline ESH User Manual
Page 3
page 3
page 6
DIMENSIONS
When installing be sure to
keep the depth to 8mm
Speciications subject to change without notice.
Tension measuring shaft
Peak switch
This switch activates or
clears peak hold reading.
Tare ring
Compression measuring shaft
Tension measuring shaft
Peak switch
This switch activates or
clears peak hold reading.
Tare ring
Compression measuring shaft
ON
ON
