– 6 –
4.0 OPERATION
Note: This device comes in two versions.
• QB-LED (40 LEDs, no laser)
• QBS-LED (118 LEDs, with laser)
Both versions are available in Standard and Pro modes (see section 4.3, Standard mode
and section 4.4, Pro mode).
4.1 Controls
No. Term Description
(D Rotary/Push Knob • Turn the knob to select the value and push to confirm. The
adjustment increment depends upon the rotational speed.
•
Turning the knob while simultaneously pushing it, effects the
adjustment increment in steps of 100.
• The flash can be turned off by
pushing the knob once and
turned on again by pushing the knob once again.
(E) Selector Switch Choose between OFF, FREQUENCY, BRIGHT, MENU and LASER
(QBS-LED version) by turning the switch to the desired position
4.2 Display
Note: Preset values are retained in each mode (Standard or Pro mode)
OVERVIEW OF ADJUSTABLE PARAMETERS
Position of
the selector
switch (E)
Display Available with Functions of the rotary/push knob (D)
Internal
trigger
External
trigger
Set value Select parameter
OFF —
FREQUENCY FPM
BRIGHT BRIGHT deg •
MENU PHASE deg • • •
INT/EXT • • • •
Following functions are only available in the PRO mode
1/min/Hz/FPM • • •
MULT. • •
BRIGHT deg/µs • • •
DELAY ms • • •
DIV • •
SLOW • •
TRIG. • •
MEM IN • • •
MEM OUT • • •
