– 9 –
No. Position of the
Selector Switch
(E)
Adjustable
Parameters
Description Display
(10) MENU INT /EXT Internal /external trigger
How to select an internal / external trigger
1. Turn the selector switch (E) to the MENU position.
2. Select the INT / EXT parameter
by turning the rotary/push knob (D).
3. Push the rotary/push knob (D) to confirm the parameter selection. The display will now show the
selection of INT and EXT parameters, the active setting will begin flashing.
4. Select the desired parameter by
turning the rotary/push knob (D).
5. Confirm and exit selection by pushing the rotary/push knob (D).
The setting is now active.
