4
Section 1. General Information
Thank you for your Flow-Through Cooler purchase. We are confident it will serve you a long time.
1.1 Unpacking
Your Flow-Through Cooler is shipped in a special carton. Retain the carton and all packing materials
until the unit is completely assembled and working properly. Set up and run the unit immediately to
confirm proper operation. Beyond one week, your unit may be warranty repaired, but not replaced. If
the unit is damaged or does not operate properly, contact the transportation company, file a damage
claim and contact the company where your unit was purchased.
1.2 Package Contents
— Flow-Through Cooler Unit
— Operators Manual
— Warranty Card
1.3 Description of Cooler
The Flow-Through Coolers are designed to be used in conjunction with circulators or other controlled
heating and pumping devices. They are built with a copper tube-within-a-tube heat exchangers. The
fluid to be cooled is circulated through the space between the tubes while the refrigerant, evaporated
to produce cooling, is inside the inner tube. The fluid contact with the cold evaporator inner tube
produces very efficient heat removal from the fluid.
1.5 Specifications
Model Flow-Through Cooler
HP 1 /
4
hp
Temperature Range -20° to +40°C
Cooling Capacity 200 Watts @ -10°C 575 Watts @ +20°C
Inlet/Outlet 3 /
8
in. FPT
Dimensions (h x d x w) 14 x 14 x 17 in.
Unit Weight 59 lbs (26.8 kg)
Power Requirements 120V, 60 Hz, 5 Amps (Operating Range 105V -125V)
240V, 50 hz, 2.5 Amps (Operating Range 200V -260V)
Section 2. Operation
2.1 Location
Locate your cooler on a level surface free from drafts and direct sunlight. Avoid areas with corrosive
fumes, excessive moisture, high room temperatures, or excessive dust. Refrigerated circulators must
be at least four inches away from walls or obstructions so air flow is not restricted.
