I.2 instrument dimensions, Figure i-2 – Brookfield DV-E Viscometer User Manual
Page 7
Brookfield Engineering Labs., Inc.
Page 7
Manual No. M98-350-J0912
I.2 Instrument Dimensions
11 47/64”
[29.8 cm]
4 5/64”
[10.4 cm]
1 7/16”
[3.7 cm]
10 7/8”
[27.6 cm]
6”
[15.3 cm]
14 41/64”
[37.2 cm]
7 13/32”
[18.8 cm]
16 23/64”
[41.5 cm]
DV-E VISCOMETER
B-20Y
LV GUARD LEG
ASSEMBLY
VS-1Y
LAB STAND BASE ASSEMBLY
Figure I-2
