Brookfield DV-E Viscometer User Manual
Page 33
Brookfield Engineering Labs., Inc.
Page 33
Manual No. M98-350-J0912
The guard leg is a part of the calibration check of the Brookfield LV and RV series Viscometer/
Rheometer. Our customers should be aware of its existence, its purpose and the effect that
it may have on data. With this knowledge, the viscometer user may make modifications to
the recommended method of operation to suit their needs.
B-21KY
Guard Leg
B-20KY
Guard Leg
5 7/8
5 5/32
For RV Torque
For LV Torque
3 3/16
1 7/16
Figure F-1
