Specifications
A-Net Output 16 channels of A-Net digital data;
Up to 16 inputs and 16 outputs simultaneously;
* 8 channels on PM1D
Interface Format Yamaha mini-YGDAI (MY) Expansion Card;
Supports MY8 and MY16 modes
Maximum Expansion limited only by the number of available MY expansion
slots in the digital mixer
Sample Rate 44.1kHz to 48kHz, +/-10%
Digital Conversion 24-bit
Digital Connections A-Net Out: 1; EtherCon® RJ45 connector
DIP Switch Switch 1-8: Stereo Link on/off
Switch 9-10: A-Net mode
A-Net Modes: 8-channel (MY8), 16-channel (MY16), Aviom,
and Test
Pro16 A-Net A-Net allows 16 channels of audio to be transmitted over
one Cat-5e cable
Use unshielded Cat-5e UTP (or better) cable;
max. length 500ft (150m) between devices
Latency <0.880 msec (measured from analog input to
analog output)
Power Supply Uses Yamaha host device as source of power
Dimensions 4.75” (120.7 mm) wide x 6.25” (158.8 mm) deep; 1.5” (38.1
mm) high
Weight 0.8 lb. (0.36 kg)
Options SB4 System Bridge; combines up to four A-Net streams for
transmission over one Cat-5e cable
All Aviom products are designed and manufactured in the USA.
