Yamaha Compatibility
The following table lists the Yamaha digital products that are compatible with the Y1 A-Net Interface
Card.
Product
Expansion Slots
Digital Channels Output via A-Net
01V96
1
16 channels per MY slot (at 48kHz)*
02R96
4
16 channels per MY slot
DM1000
2
16 channels per MY slot
DM2000
6
16 channels per MY slot
PM5D
4
16 channels per MY slot
PM5D-RH
4
16 channels per MY slot
M7CL (32 & 48)
3
16 channels per MY slot
LS9-16
1
16 channels per MY slot
LS9-32
2
16 channels per MY slot
PM1D
8
Limited to 8 channels per MY slot
DME24N
1
16 channels per MY slot
DME64N
4
16 channels per MY slot
CL1
3
16 channels per MY slot
CL3
3
16 channels per MY slot
CL5
3
16 channels per MY slot
* Yamaha’s MY16 mode provides 16 channels per card slot at 44.1/48kHz; MY8 mode provides 8 channels
per slot at 48kHz or 96kHz. Not all Yamaha devices are capable of operating at 96kHz.
