37

A-16ii P

ersonAl

M

ixer

U

ser

G

Uide

Audio Outputs

1/4” TRS stereo, headphone or line level

Line/Headphone TRS

Output

Tip: Audio Left; Ring: Audio Right;

Sleeve: Ground
Auto-detects mono plugs

A-Net I/O

1 A-Net In, 1 A-Net Out; RJ45 connectors

D/A Conversion

44.1/48kHz, 24-bit

Indicators

Pan: 5 LEDs, 4 red, 1 green;

Channel Volume: 12 red LEDs

Stereo Operation

Stereo Link, per channel pair; set at the input module

Variable pan/spread per channel or channel pair

Tone Controls

Treble: +/-12dB at 9kHz shelving

Bass: +/-12dB at 160Hz shelving

Maximum Level

(RMS)

1.0 watt at 100 Ohms

(Line/Headphone output)

Output Impedance

32 ohms

Freq. Response

4Hz-22kHz +0.2dB/-3dB

THD +N

< 0.003%

Crosstalk

-90dB

Signal to Noise

(unweighted)

-90dB typical, A/D to D/A
Measured from AN-16/i to A-16II

Latency

0.880 msec (measured from analog input to analog output)

Pro16 A-Net

Uses unshielded Cat-5e UTP (or better) cable; maximum

500ft (150m) between devices

Power Supply

Input Voltage

Output Voltage

Plug Size

External, DC, universal switching type

100-240 volts, 50/60Hz, 30VA

18-24 VDC, 0.5 amp

2 mm

Dimensions

10.75” (273 mm) wide x 5.6” (142.2 mm) deep;

2.25” (57.5 mm) high

Weight

3.4 lb. (1.54 kg)

Options

PS-120 Power Supply

MT-1a Mic Stand Bracket (uses 6-32, 1/4-inch machine

screws)

EB-1 Extension Bracket

All Aviom products are designed and manufactured in the USA.

A-16II Personal Mixer Specifications
