A Preset is saved when the numbered button is released.
Global Controls
The three knobs in the upper right section of the A-16II Personal Mixer affect your overall mix volume and
tone directly. The Bass, Treble, and Master volume controls are always active, regardless of the state of the
current mix or selected Preset. These are analog controls and their settings are not stored as part of a mix
preset.
Tone Controls
Use the Bass and Treble controls to change the overall balance of bass or treble frequencies in your mix.
These controls affect the entire mix, not the individual channels.
The global Bass, Treble, and Master volume controls
The default position for the B
aSS
and t
ReBle
knobs is at 12 o’clock. To add more low frequencies to your
monitor mix, turn the B
aSS
knob to the right of the 12 o’clock position. To remove lows, turn the knob
counterclockwise past the center. To change the high-frequency content, follow the same procedure; turn
the t
ReBle
knob right to add highs, left to diminish them.
The Bass and Treble EQs in the Personal Mixer are both shelving type. There is +/-12dB of cut or boost
available for each.
+12dB
-12dB
+12dB
-12dB
160Hz 9kHz
The shelving Bass EQ has a corner frequency of 160Hz. The Treble EQ is also a shelving type, with a 9kHz corner
frequency.
Master Volume
The overall system volume is controlled by the M
aSteR
volume control. This is an analog control. Turn it
counterclockwise for a full off setting. As a general suggestion, start with the Master volume knob at a low
setting, about 9 or 10 o’clock to start. Raise the volume slowly from that point to a comfortable listening
level.
