MAXX-2400HD Owner’s Manual Page 61
The Playlist View
The playlist view for channel 1 is shown in Figure 22. Its functions are briefly described here.
Table 1 provides an overview of Playlist control functions and their associated hot-keys.
Figure 22 - Channel 1 Playlist View
FUNCTION DESCRIPTION / REFERENCE INVOKE HOT-KEY
PLAY/ PAUSE Play / Pause a clip ( Page 46, 64 ) PLAY Button P or SPACE
STOP/ SHOW Stop / Show First Frame ( Page 64 ) STOP Button S
CUE Cue a clip ( Page 64 ) CUE Button C
NEXT Prepare next clip for playback ( Page 64 ) NEXT Button N
JUMP Jump to the selected clip ( Page 64 ) JUMP Button J
LOOP Check to loop a Playlist ( Page 64 ) LOOP
Checkbox
L
EDIT Check to enable editing ( Page 65 ) EDIT
Checkbox
E
ARM START TIME Enable Scheduled Start Time ( Page 63 ) ARM START
TIME
Checkbox
T
HOME Scroll to currently playing Clip ( Page 64 ) HOME
Button
H
Table 1 - Playlist Control Functions
