Step 1. To remove the OEM exhaust system, unbolt the
flange and clamp attaching the systems inlet pipes to the
catalytic converter outlet pipes. Disengage all welded
hangers from the OEM rubber insulators. Do not discard
the OEM fasteners or damage the rubber insulators as
they will be needed to mount your new MAGNAFLOW
system.
Step 2. Install the new system by attaching the Inlet
Y-Pipe Assembly to the OEM catalytic converter outlet
pipes using the existing clamp and hardware. Locate the
welded hanger to the rubber insulator. Leave all clamps
and fasteners loose for final adjustment of the complete
system once installed.
Step 3. Install the Muffler using the supplied 3.50"
clamp. Use the supplied 16.00" Extension Pipe between
the Muffler and the Tail Pipe Assembly if your truck uses
the Crew Cab Long Bed or the Extended Cab Short Bed
configuration. If your truck has a Crew Cab with the
Short Bed the 16.00" Extension Pipe is not used.
Step 4. Install the Muffler, Tail Pipe Assembly and
Extension Pipe Assembly (if needed) using the supplied
3.50" clamps. Locate the welded hangers to the OEM
rubber insulators.
