9032100E2 Application View
5-7
Port Pair Application (Dot1dPtPairApp)
Port Pair Application (Dot1dPtPairApp)
The following information is available for the Port Pair Application.
Bridge Port Pair Table
Access this table from the Port Pair App icon in the Application view. Select
Bridge Port Pair Table from the Icon Subviews menu. The resulting table
view, Dot1d Bridge Port Pair Information table, provides the following
information:
Total Ports
The total number of ports available for the device.
MAC Address
The physical address of the interface.
Bridge Type
The bridge type for this interface is Source Route Transparent (SRT).
Low Port
The port number of the lower numbered port for which this entry contains
port pair database information.
High Port
The port number of the higher numbered port for which this entry contains
port pair database information.
Bridge Number
The bridge number that uniquely identiÞes the path provided by this source
routing bridge between the segments connected to dot1dPortLowPort and
dot1dPortPairHighPort. The purpose of bridge number is to disambiguate
between multiple paths connecting the same two LANs.
Bridge Status
The status of the bridge; Enabled or Disabled.
Recoveries This counter is incremented when a station recognizes a frame
addressed to its speciÞc address, but has no available buffer
space indicating that the station is congested.
Token The total number of times the station acting as active monitor
recognizes an error condition requiring a token be transmitted.
Table 5-3. Non-Isolating Errors Pie Chart (Continued)
Statistic DeÞnition
