9032100E2 Device Views
2-7
Interface Device View
Logical Interface Icons
Last Change
The System UpTime value when the interface entered its current operational
state. This is provided in the format: D + HH:MM:SS, for example, 1+20:40:25
if the TSX-1620 has been active for one day and 20 hours, 40 minutes and 25
seconds.
Network Name/Address
The IP Address assigned to the TSX-1620.
Physical Address
The Ethernet (MAC) address of the interface.
Bandwidth
The estimated bandwidth of the interface measured in bits per second. For
interfaces that do not vary in bandwidth, or when no accurate estimate can be
made, a nominal bandwidth is provided.
Packet Size
The largest packet that can be transmitted or received by the port, measured
in octets.
Queue Length
The length of the outbound packet queue, in packets.
Physical Address Label/IF Address Translation Table
This label displays the physical address of the device interface.
Double-clicking on this label accesses the Interface Address Translation
Table. This table cross-references device IP addresses to device MAC
(Ethernet) addresses for selected nodes between networks. Double-clicking on
any column entry opens an address-speciÞc Address Translation Table
Information view.
IP Address Label/Network Information Panel
This label displays the IP Address address of the device. Double-clicking on
this label accesses the Network Information Panel. This panel provides Name,
Network Address, and subnet mask information for the interface for the
TSX-1620.
