Interface Device View
Logical Interface Icons
Device Views
2-6 TSX-1620
Management Module Guide
Interface Number Label/Device Topology View
This label displays the interface number identifying this interface.
Double-clicking on this label accesses the TSX-1620 Device Topology (DevTop)
view.
Administrative Status Label/IF Status View
Provides access to conÞguration views speciÞc to the port. Double-clicking on
this label of the Interface icon accesses the TSX-1620 Interface Status view.
Table 2-1 shows the possible interface statuses and their respective colors.
Table 2-1. Interface Status Label DeÞnitions
Operational Status
A read-only indicator button displaying the current operational state of the
interface (ON, OFF, or Testing).
Administrative Status
The desired operational state of the interface (Default, ON, OFF, or Testing).
You may change the value for Administrative Status.
Interface Type Label/IF ConÞguration View
This label displays the type of TSX-1620 interface. Double-clicking on the IF
ConÞguration view label accesses the Interface ConÞguration view, which
provides the following information:
Operation Status
This read-only Þeld provides the current operational state of the interface
(On, Off, or Testing).
Admin Status
You can select the desired operational state of the interface (On, Off, or
Testing).
Operational
Status
Administrative
Status
Text Display Color
ON ON ON Green
OFF OFF OFF Blue
OFF ON OFF Yellow
Testing Testing Test Red
