Interface ConÞguration View
ConÞguration Views
3-4 TSX-1620
Management Module Guide
Last Change
The System UpTime value when the port entered its current operational
state.
Queue Length
The length of the outbound queue of packets.
Packet Size
The largest Maximum Transmission Unit (MTU) that can be transmitted or
received by the port, measured in octets.
Double-clicking on any column entry for a particular port accesses the
Interface ConÞguration view. This view is described below.
Interface ConÞguration View
Access the IF ConÞguration view by highlighting an Interface icon in the
Interface Device view, and selecting IF ConÞguration from the Icon
Subviews menu. The IF ConÞguration view provides the following
information:
Admin Status
The desired operational state of the port (On, Off, or Testing). You can change
the Admin Status in this view.
Network Name/Address
Displays the network name and IP address for this TSX-1620.
