9032100E2 Device Views
2-9
Interface Device View
Interface Options Panel
Figure 2-3. Gauge Control Panel
To access the Gauge Control Panel, double-click on the Interface Options
Panel, or single-click on the panel to highlight it and then select Gauge
Control Panel from the Icon Subviews menu. The Gauge Control Panel
provides the following information:
¥ Selected Attribute
¥ Gauge Mode
¥ Gauge Type
¥ Logical Gauge Buttons
Selected Attribute
This area of the Gauge Control Panel allows you to select the statistical
attribute displayed on the Logical Interface iconÕs gauge. The label changes
color to reßect the attribute selected.
Gauge Mode
This area of the Gauge Control Panel allows you to select the mode presented
by the Logical Gauge. Possible selections are Totals, Rates, or Percentages.
The Percentages selection presents the percentage of the interface compared
to the rest of the interfaces. Table 2-2 provides a list of attributes and color
deÞnitions for the Totals mode. Table 2-3 provides a list of attributes and color
deÞnitions for the Rates mode.
Gauge Mode Selected Attribute
Rates Load
Totals Load In
Percentages Load Out
Packet Rate
Gauge Type Packet In Rate
Packet Out Rate
Numeric Error Rate
Linear Error In Rate
Apply Keep Settings
Reset Close
Default
Gauge Control Panel
Logical
Gauge
Buttons
