Carrier 58PHA/PHX - Manual (Page 15)

15
UPFLOW DOWNFLOW HORIZONTAL
YES
NO NO
YES
YES
YES
NO
120°
MIN
YES 120°
MIN
YES 120°
MIN
90° 90°
A02020
Fig. 14 -- Duct Flanges
1 / 4
" (6mm) THREADED ROD
4 REQ.
SECURE ANGLE
IRON TO BOTTOM
OF FURNACE WITH
3 #8 x 3 / 4 " (19mm) SCREWS
TYPICAL FOR 2 SUPPORTS
1” (25mm) SQUARE, 1-1/4”x1-1/4”x1/8” (32x32x3mm)
ANGLE IRON OR UNI-STRUT MAY BE USED
(2) HEX NUTS, (2) WASHERS & (2) LOCK WASHERS
REQ. PER ROD
8" (203mm) MIN
FOR DOOR REMOVAL
OUTER DOOR
A S SEMBLY
A05027
Fig. 15 -- Horizontal Unit Suspension
58PH
A
