4. INSTALLATION INSTRUCTIONS FOR THE PROFESSIONAL

Table 4.1.1 shows some typical components available for several common arrangements of SOL 27 Premium collectors.

Item

Part No.

Collector Clamps for SOL 27 Premium

S267510

SE Flowstar Pump Station kit, including: circulator, expansion tank, pressure relief valve, 2 boiler
drains, temperature/pressure gauge, flowmeter, check valve, return line thermometer, air vent

221339

SOM 6 Plus differential temperature controller for one control function and 4 sensor inputs; V-bus
ready; (2) FKP6 temperature sensors included

230141

SOM 7 Plus differential temperature controller for two control functions and 4 sensor inputs;
V-bus ready; (4) FKP6 temperature sensors included

230142

SOM 9 SI, temperature differential controller ; V-bus; (6) FKP6 temperature sensors included

11566327

Data logger DL2

18000710

VBUS to USB adapter

18000860

Small solar system display

18000777

Pt1000 (1K RTD type) temperature sensor for SOM controllers

165818

Flow meter Max. 5.2 GPM

28001107

Flow meter Max. 13.2 GPM

28001117

Interconnecting stainless steel tube for SOL 27 Premium panels

230185

Inlet and outlet tube set with temperature sensor

230913

Inlet or outlet tube (single) without temperature sensor

231683

Dowfrost™ 50 ready-mixed propylene glycol heat transfer medium, (5.0 U.S. gallons, 19 liters,
contains 50% propylene glycol) - jug

074200

Expansion tank, diaphragm-type (2.0 gal.)

ST116

SB 150 S (150 liter, 40-gal.) solar storage tank, single HX

221220

SB 200 S (200 liter, 52-gal.) solar storage tank, single HX

221221

SBB 300 S (300 liter, 82-gal.) solar storage tank, single HX; includes STAK-003 connection kit

221219

SBB 400 S (400 liter, 110-gal.) solar storage tank, single HX; includes STAK-003 connection kit

221222

SBB 300 Plus (300 liter, 82-gal.) solar storage tank, double HX; includes STAK-002 connection kit

187873

SBB 400 Plus (400 liter, 110-gal.) solar storage tank, double HX; includes STAK-002 connection kit

187874

SBB 600 Plus (600 liter, 163-gal.) solar storage tank, double HX; includes STAK-002 connection kit

187875

Red indicator for SBB anode rods

140919

Anode rod for SBB 300-400 tanks

249041

Anode rod for SBB 600 tank

249042

Segmented (flexible) replacement anode for SBB tanks

143499

Gasket for anode rod

036770

Thermometer for SBB Tanks

165967
