- Page 29 -
G. CORE TEMPERATURE ( o F)
VS.
MILLIVOLTS (DC)
(FIGURE 20)
0 5 10 15 20 25 30
1800 o
1600 o
1400 o
1200 o
1000 o
800 o
600 o
400 o
200 o
Core Temperature (
o
F)
Millivolts (DC)
(From Core Temperature Sensor, DWG Ref. No. 15 on Figure 10)
