- Page 14 -
B. UNIT SPECIFICATIONS
1 kW = 3412 BTU/HR 1 kWh = 3412 BTU
MODEL: HPB11B
•MINIMUM CHARGING CIRCUIT SERVICE
60 Amps (240V systems)
ENTRANCE PANEL
(46 Amps x 1.25 = 57 Amps)
•MAXIMUM BLOWER LOAD
2 Amps (240V systems)
•CHARGING INPUT
11.0 kW
•kWh STORAGE
75 kWh
•HEATING ELEMENTS
6 - 1830W Incoloy Sheathed
•STORAGE BRICK (Magnetite)
861 LBS
•APPROXIMATE INSTALLED WEIGHT
1200 LBS
•UNIT SIZE (Height-Length-Depth)
51" X 26.5" X 34.5"
•MAXIMUM DELIVERABLE kWh/24 HOURS
8 Hour Charge
88 kWh
=
300,256 BTU
12 Hour Charge
132 kWh
=
450,384 BTU
MODEL: HPB15B
•MINIMUM CHARGING CIRCUIT SERVICE
80 Amps (240V systems)
ENTRANCE PANEL
(62 Amps X 1.25 = 77 Amps)
•MAXIMUM BLOWER LOAD
2 Amps (240V systems)
•CHARGING INPUT
14.7 kW
•kWh STORAGE
100 kWh
•HEATING ELEMENTS
8 - 1830W Incoloy Sheathed
•STORAGE BRICK (Magnetite)
1107 LBS
•APPROXIMATE INSTALLED WEIGHT
1500 LBS
•UNIT SIZE (Height-Length-Depth)
58" X 26.5 X 34.5"
•MAXIMUM DELIVERABLE kWh/24 HOURS
8 Hour Charge
117 kWh
=
399,204 BTU
12 Hour Charge
176 kWh
=
600,512 BTU
MODEL: HPB22B
•MINIMUM CHARGING CIRCUIT SERVICE
125 Amps (240V systems)
ENTRANCE PANEL
(92 Amps X 1.25 = 115 Amps)
•MAXIMUM BLOWER LOAD
2 Amps (240V systems)
•CHARGING INPUT
22 kW
•kWh STORAGE
135 kWh
•HEATING ELEMENTS
12 - 1830W Incoloy Sheathed
•STORAGE BRICK (Magnetite)
1600 LBS
•APPROXIMATE INSTALLED WEIGHT
2100 LBS
•UNIT SIZE (Height-Length-Depth)
72" X 26.5 X 34.5"
•MAXIMUM DELIVERABLE kWh/24 HOURS
8 Hour Charge
176 kWh
=
600,512 BTU
12 Hour Charge
264 kWh
=
900,768 BTU
