Outdoor unit, Air intake vents, Air outlet vent – Panasonic CS-1873KR User Manual
Page 5: Piping, 3) indoor unit, outdoor unit
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
(3) Indoor Unit, Outdoor Unit
Panel Opener
(Left And Right Sides)
Horizontal
Airflow
Direction
Louver
Vertical Airflow Direction Louver
(TWIN FLAP)
Receives the signals from the remote
control.
(Signal received sound; two short
beeps or one long beep)
Operation Indication Lamp
Illuminates when the air conditioner is
in operation.
(Blinks at the start of automatic
operation or defrosting operation and
hot start operation in heating mode.)
Outdoor Unit
Air Intake Vents
Air Outlet Vent
Piping
Drain Hose
