Location of Controls

Remote Control Buttons

POWER

See pages 8, 11.

CHANNEL UP/DOWN
SELECT UP/DOWN
See pages 8~14,16,18-24.

NUMBERED KEY
See pages 9, 11,16, 22.

INDEX
See pages 22, 23.

REWIND/SEARCH

See pages 15, 22, 23.

ADD/DELETE
See pages 8, 9, 13, 19, 20.

STOP

See pages 15,16, 19, 23.

NITE/GAME

See page 11.

VOLUME UP/DOWN

SET/BACKSPACE

See pages 8-14,16,18-24.

TRACKING UP/DOWN

See page 15.

ON-TIMER

See page 13.

RECORD/TIME

See page 16.

ZERO/1 MINUTE SKIP

See page 24.

SLOW

See page 15.

COUNTER RESET

See page 24.

Rear View of the Combination VCR

AC Power Plug -----
When plugged into an AC
outlet, the Combination VCR
consumes 5 W of electric

power in OFF condition.

VHF/UHF Antenna
Input Terminal

In from your

Antenna or Cable.

See page 5.
