How to connect the “AV1,2 or 3” Input Terminals.

(Super-VHS VCR)

(VHS VCR)

R=€m]|S>i4

^== ^ €

■

1^:']! O

511-.iU.

V iliOwTOft

AVI

AV3 ^

-r

(3-VIDEO'i

(' viOEd'") .

!© © ©

-!|©

Uijrio

■' Cljifn ■

C AUDIO )

r WOHtT).

1© © ©

Note:

{1) When AV1, AV2 or AV3 is selected, and that AV mode has no input picture signal, the Background Colour of the

TV screen will change. (This only occurs If the Blue-Back function is set to the ON condition; refer to pages 34

and 35 for details.)

(2) When an S-Video cable is connected to the S-Video terminal, the Phono Video input will be automatically

switched off for that AV mode.

(3) When a Monaural VCR is used, connect the Monaural Audio cable to the Audio “L" (Left) terminal.

(4) Similar connections are available at the AV1, AV2 and AV3 input terminals.

Select the desired AV input position by pushing the TV/AV button. (Refer to page 24)
