SPECIFICATIONS
:
y
■ : : ^
^ I - : * - ' ‘
^
■*.^ r
NV-G25A, EA
I
Power Source:
NV-G25A; 240 V AC 50-60 Hz
NV-G25EA: 230 V AC 50-60 Hz
Power Consumption:
Approx. 25 watts
m m m u
Video Recording System:
Tape Speed:
Tape Format:
Record/Playback Time:
FF/REWTime:
2 rotary heads, helical scanning system
SP: 23.39 mm/sec.
LP; 11.695 mm/sec.
TO tape
SP: 240 min. with NV-E240
LP: 480 min. with NV-E240
Less than 5.5 min. with NV-E180
VIDEO
Television System:
Modulation System:
Input Level:
Output Level:
CCIR; 625 lines, 50 fields, PAL colour signal
Luminance: FM azimuth recording
Colour signal: converted subcarrier phase shift recording
VIDEO IN (PHONO):
1.0 Vp-p,
VIDEO OUT (PHONO):
1.0 Vp-p,
RF Modulated:
NV-G25A: VHF channel 0 or 1,
NV-G25EA: VHF channel 2 or 3,
75 ohm, unbalanced
75 ohm, unbalanced
75 ohm, unbalanced
75 ohm, unbalanced
AUDIO
Input Level:
Output Level:
Audio Track:
Video Horizontal Resolution:
Signal-to-Noise Ratio:
-10 dB,
- 8 d B ,
Audio Frequency Response:
Operating Temperature:
Operating Humidity:
Weight:
Dimensions:
Standard Accessories:
AUDIO IN (PHONO);
AUDIO OUT (PHONO):
1 track monaural
Colour; more than 240 lines (SP)
Video; more than 43 dB (SP)
Audio; more than 43 dB (SP)
80 Hz-10 kHz (SP)
5“C-40“C
35%-80%
5.5 kg
430 (W)x82 (H)x360 (D) mm
1 pc. DIN-DIN coaxial cable
1 pc. Programmable Remote Controller (Infra-red)
1 pc. AC Mains Lead
1 pc. Digital Scanner
more than 50 kohm, unbalanced
less than 1 kohm, unbalanced
Weight and dimensions shown are approximate.
Specifications are subject to change without notice.
