Pin Assignment

AES B Hot

AES7'£oid
AES 6 Hoi

GNC

AES 8 Cold
AES 7 Hot

GND
AES 6 Cold

AES 4 Cold

AES 3 Hot

GND

AES 2 Cold
AES 1 Hot

GND

AES

Hot

^?Fip~

AES 3 Cold

AESg-HgL

GNp " “ .

AES

Cold

Not used

Recommended Cable

Panasonic part #

DA/DB-XLRM

(DB-25 to 8 Male XLR,Length 3m), AD

Output cable is recomended.

Specifications

Output Connector

Format

Signal Level

Channel Mode

Dimensions

Weight

DB25

A1:S/EBU (24 bit AES3-1992)

RS-422

8 ch, 24-bit, 44.1/48 kHz, Normal AES

8 ch, 24-bit, 88.2/96 kHz, Hi-Speed AES

8 ch, 24-bit, 88.2/96 kHz, Dual AES

108(W)x37(H)x62(D) mm

4-l/4(W) X l-7/l6(H) X 2-7/l6(D) inch

230 g (0.51 lbs)
