or an equivalent protective covering. Cap open ends of pipes
stored on the jobsite. This precaution is especially important in
areas where painting, plastering, or spraying of fireproof mate-
rial, etc. is not yet complete. Foreign material that accumulates
within the units can prevent proper start-up and necessitate
costly clean-up operations.
Before installing any of the system components, be sure to
examine each pipe, fitting, and valve, and remove any dirt or
foreign material found in or on these components.
INSPECT UNIT — To prepare the unit for installation, com-
plete the procedures listed below:
1. Compare the electrical data on the unit nameplate with
ordering and shipping information to verify that the
correct unit has been shipped.
2. Verify that the unit is the correct model for the entering
water temperature of the job.
3. Do not remove the packaging until the unit is ready for
installation.
4. Verify that the refrigerant tubing is free of kinks or dents,
and that it does not touch other unit components.
5. Inspect all electrical connections. Be sure connections are
clean and tight at the terminals.
6. Loosen compressor bolts until the compressor rides freely
on springs. Remove shipping restraints.
7. Remove the four
1
/
4
in. shipping bolts from compressor
support plate (two bolts on each side) to maximize vibra-
tion and sound alternation.
8. Remove any blower support cardboard from inlet of the
blower.
9. Locate and verify any accessory kit located in compressor
section.
10. Remove any access panel screws that may be difficult to
remove once unit is installed.
Table 1 — Physical Data — 50PCH,PCV Units
LEGEND
*Front is located at control box end.
NOTES:
1. All units have grommet compressor mountings, and
1
/
2
-in. and
3
/
4
-in. electrical knockouts.
2. Maximum water working pressure is 500 psig.
CAUTION
DO NOT store or install units in corrosive environments or
in locations subject to temperature or humidity extremes
(e.g., attics, garages, rooftops, etc.). Corrosive conditions
and high temperature or humidity can significantly reduce
performance, reliability, and service life. Always move
units in an upright position. Tilting units on their sides may
cause equipment damage.
CAUTION
Failure to remove shipping brackets from spring-mounted
compressors will cause excessive noise and could cause
component failure due to added vibration.
50PCH,PCV UNIT
006
009
012
015
018
024
030
036
042
048
060
COMPRESSOR (1 each)
Rotary
Scroll
REFRIGERANT TYPE
R-410A
Factory Charge (oz)
17
18.5
23
32
43
43
47
50
70
74
82
FAN MOTOR AND BLOWER
Fan Motor Type/Speeds
PSC/3
Fan Motor (hp)
1
/
25
1
/
10
1
/
10
1
/
6
1
/
6
1
/
4
3
/
4
1
/
2
3
/
4
3
/
4
1
Blower Wheel Size (Dia x W) (in.)
5 x 5
6 x 5
8 x 7
9 x 7
9 x 8
10 x 10
11 x 10
COAX VOLUME (gal.)
0.123
0.143
0.167
0.286
0.450
0.286
0.323
0.323
0.890
0.738
0.939
WATER CONNECTION SIZE FPT (in.)
1
/
2
3
/
4
1
HORIZONTAL
Air Coil Dimensions (H x W)(in.)
10 x 15
16 x 22
20 x 25
20 x 35
Standard Filter - (Qty)
1 in. Throwaway
(1) 10 x 18
(1) 16 x 25
(1) 18 x 25
(1) 20 x 28 or
(2) 20 x 14
(1) 20 x 24,
(1) 20 x 14
Weight (lb)
Operating
103
105
114
153
158
174
182
203
218
263
278
Packaged
113
115
124
158
163
179
187
209
224
270
285
Corner Weight (lb)*
Left-Front
37
38
42
53
55
62
67
75
81
98
103
Right-Front
24
24
26
36
37
40
41
47
50
60
64
Left-Back
23
23
25
34
35
39
40
44
48
58
61
Right-Back
19
20
21
30
31
33
34
37
39
47
75
VERTICAL
Air Coil Dimensions (H x W)(in.)
10 x 15
20 x 17.25
24 x 17.75
24 x 28.25
Standard Filter - (Qty)
1 in. Throwaway
(1) 10 x 18
(1) 20 x 20
(1) 24 x 24
(1) 14 x 24,
(1) 18 x 24
Weight (lb)
Operating
103
105
114
153
158
189
197
203
218
263
278
Packaged
113
115
124
158
163
194
202
209
224
270
285
FPT — Female Pipe Thread
PSC — Permanent Split Capacitor
