Specifications
AUDIO SECTION
• Miniiniiin RMS Output Power for Front, Center, Surround
[U.S.A. and Canada models]
1 kHz, 0.9% THD, 8 Q ............................................ 100 W/ch
[Other models]
1 kHz, 0.9% THD, 6 Q ............................................... 100 W/ch
• Maximum Power (JEITA)
[U.S.A. and Canada models]
1 kHz, 10% THD, 8 Q ................................................ 135 W/ch
[Asia, China, Korea and General models]
1 kHz, 10% THD, 6 Q ................................................. 135 W/ch
• MAX Power Per Channel
[U.K., Russia, and Europe models]
1 kHz, 0.7% THD, 4 Q ...................................... 105 W or more
• lEC Power
[U.K., Russia, and Europe models]
1 kHz, 0.1 % THD, 6 Q ....................................... 90 W or more
• Dynamic Power
[U.S.A. and Canada models] (Impedance Selector: 8 Q)
(IHF, 8/6/4Z2 Q) ........................................ 110/130/160/180 W
[Other models]
(IHE 6/4/2 Q)..................................................... 105/130/150 W
• Dynamic Headroom [U.S.A. and Canada models]
8Q....................................................................................... 0.41 dB
• Erequency Response
CD, etc. to Front.................................. 10 Hz to 100 kHz, 0/-3 dB
V-AUX to Front.................................... 10 Hz to 20 kHz, 0/-3 dB
• Total Harmonic Distortion
CD, etc. (2ch stereo) to Front SP OUT,
[U.S.A. and Canada models]
1 kHz, 50 W/8 Q ...................................................0.06%' or less
[Other models]
1 kHz, 50 W/6 Q ...................................................0.06%' or less
• Signal to Noise Ratio (IHF-A Network)
CD, etc. (STEREO) Input shorted
250 mV................................................................ 100 dB or more
200 mV..................................................................98dBor more
• Residual Noise (IHF-A Network)
Front L/R ................................................................ 170 uV or less
• Channel Separation
CD, etc. Inputs.1 kO shorted(l kHz/lOkHz)
................................................................... 60 dB/45 dB or more
• Tone Control
BASS Boost/Cut.................................................... ±10 dB/100 Hz
TREBLE Boost/Cut ................................................ ±10dB/20kHz
• Headphone Jack Rated Output/Impedance
CD, etc. (1 kHz, 200 mV, 8 Q)................................... 0.4 V/470 Q
• Input Sensitivity/Input Impedance
CD, etc.................................................................... 200 mV/47 kQ
MULTI CH INPUT ............................................... 200 mV/47 kQ
• Maximum Input Signal
CD, etc. 1 kHz, 0.5%THD (EFFECT ON) ............. 2.0 V or more
• Output Level/Output Impedance
AUDIO OUT (REC) ............................................ 200mV/1.2kQ
SUBWOOFER OUTPUT
(2ch Stereo and FRONT SP; SMALL) .................... 4 V/1.2 kQ
• Filter Characteristics (fc=40/60/80/90/100/110/120/160/200 Hz)
H.P.F (Front, Center, Surround) ................................... 12dB/oct.
L.PF (Subw'oofer) ......................................................... 24 dB/oct.
VIDEO SECTION
• Signal Level
Composite.................................................................. 1 Vp-p/75 Q
Component ................... 1 Vp-p/75 Q (Y), 0.7 Vp-p/75 Q (P
b /P r )
• Video Maximum Input Level................................. 1.5 Vp-p or more
• Signal to Noise Ratio.................................................. 50 dB or more
• Frequency Response (MONITOR OUT)
Component Signal ................................... 5 Hz to 60 MHz, -3 dB
FM SECTION
• Tuning Range
[U.S.A. and Canada models] .......................... 87.5 to 107.9 MHz
[Asia and General models].........87.5/87.50 to 108.0/108.00 MHz
[Other models] ............................................ 87.50 to 108.00 MHz
• 50 dB Quieting Sensitivity (IHF, 100% mod.)
Mono.................................................................. 2.8 ,LiV (20.2 dBf)
• Signal to Noise Ratio (IHF)
Mono/Stereo .............................................................. 73 dB/70 dB
• Harmonic Distortion (1 kHz)
Mono/Stereo ................................................................. 0.5%/0.5%'
AM SECTION
• Tuning Range
[U.S.A. and Canada models] .............................. 530 to 1710 kHz
[Asia and General models] ................. 530/531 to 1710/1611 kHz
[Other models] .................................................... 531 to 1611 kHz
GENERAL
• Power Supply
[U.S.A. and Canada models] ............................. 120 VAC, 60 Hz
[Australia model] ............................................... 240 V AC, 50 Hz
[Korea model] .................................................... 220 V AC, 60 Hz
[China model] .................................................... 220 V AC, 50 Hz
[U.K., Russia, and Europe models]................... 230 V AC, 50 Hz
[Asia and General models]
............................................ 110-120/220-240V AC, 50/60HZ
• Power Consumption
[U.S.A. and Canada models] ................................. 240 W/320 VA
[Other models] .................................................................... 240 W
Standby Power Consumption
[Except Asia and General models]
Maximum Power Consumption
[Asia and General models]
5ch, 10%/THD.............................
0.8 W
530 W
Dimensions (W x H x D).................................. 435 x 151 x 318 mm
(17-1/8” x5-15/Kwx 12-1/2”)
Weight...............................................................8.0 kg (17 lbs 10 oz)
■ Specifications are subject to change without notice.
